Self erecting cranes

These cranes are designed to be transported in a single truck or using a tractor head, and to be installed quickly, in places where space is tight, and without the need for auxiliary mobile cranes.

They are usually used for the construction of detached houses, or for smaller industrial projects.

In SAEZ cranes we have designed a range of self-erecting cranes with the same philosophy that we apply to our tower cranes: the pursuit of simplicity, robustness and durability. We pay great attention to the details too: the final dimensions of the cranes once folded mean they can be transported in containers of 40’ HC, avoiding the expensive Flat-rack containers.

Model Max load (Kg) JiB (m) Tip Load (t) Half JiB Load (t) Max Height under Hook (m) Power Requirement PDF
H 42-13 5000
42-37-32
1,3-1,55-2,05
-
23-35/15º-49
29 Kw
H 40 5000
40-35-29,3
1,1-1,5-1,7
5,00
23,2/15º-27,7
23 Kw
H32 SR/DR 4000
32-30-27,7
1,0-1,2-1,4
2,00
21/15º-27,4
13 Kw
H 28 2000
28
0,75
2,00
20,7/15º-26,4
13 Kw
H24 - TF 1600
24-22-20
0,7-0,85-1,0
1,60
18/15º-23,7
6,5 Kw
H 24 - MTF 1500
24-22-20
0,7-0,85-1,0
1,50
18/15º-23,7
8 Kw
